Description

A set of very simple models & API for handling them.

Usage

Models

simple_models_cube_1x2x1:

• for nodes with dimensions 1x2x1

• preview:



• texture map:



simple_models_panel_1x2x1:

• for door or panel-like nodes with dimensions 1x2x1

• preview:



• texture map:



simple_models_panel_mid_1x2x1:

• for door or panel-like nodes with dimensions 1x2x1 positioned in center
• same texture map as simple_models_panel_1x2x1

simple_models_panel_rear_1x2x1:

• for door or panel-like nodes with dimensions 1x2x1 positioned at rear
• same texture map as simple_models_panel_1x2x1

simple_models_stair_2s_1x1x1:

• for stair-like nodes with dimensions 1x1x1

• preview:



• texture map:



simple_models_stair_4s_1x1x1:

• for stair-like nodes with dimensions 1x1x1

• preview:



• texture map:



simple_models_slope_1x1x1:

• for slope-like nodes with dimensions 1x1x1

• preview:



• texture map:



simple_models_slope_1x1x2:

• for slope-like nodes with dimensions 1x1x2

• preview:



• texture map:



Tables

There are some tables for accessing pre-defined attributes:

simple_models.cube_1x2x1:
- fields:
    - mesh: "simple_models_cube_1x2x1.obj"
    - box:  {-0.5, -0.5, -0.5, 0.5, 1.5, 0.5}
- alias: simple_models.cube

simple_models.panel_1x2x1:
- fields:
    - mesh: "simple_models_panel_1x2x1.obj"
    - box:  {-0.5, -0.5, -0.5, 0.5, 1.5, -0.45}
- alias: simple_models.panel

simple_models.panel_mid_1x2x1:
- fields:
    - mesh: "simple_models_panel_mid_1x2x1.obj"
    - box:  {-0.5, -0.5, 0.025, 0.5, 1.5, -0.025}
- alias: simple_models.panel_mid

simple_models.panel_rear_1x2x1:
- fields:
    - mesh: "simple_models_panel_rear_1x2x1.obj"
    - box:  {-0.5, -0.5, 0.45, 0.5, 1.5, 0.5}
- alias: simple_models.panel_rear

simple_models.stair_2s_1x1x1:
- fields:
  - mesh: "simple_models_stair_2s_1x1x1.obj"
  - box:  {{-0.5, 0.0, 0.0, 0.5, 0.5, 0.5}, {-0.5, -0.5, -0.5, 0.5, 0.0, 0.5}}
- alias: simple_models.stair_2s

simple_models.stair_4s_1x1x1x:
- fields:
  - mesh: "simple_models_stair_4s_1x1x1x.obj"
  - box:  {
      {-0.5,  0.25,  0.25, 0.5,  0.5,  0.5},
      {-0.5,  0.0,   0.0,  0.5,  0.25, 0.5},
      {-0.5, -0.25, -0.25, 0.5,  0.0,  0.5},
      {-0.5, -0.5,  -0.5,  0.5, -0.25, 0.5},
    }
- alias: simple_models.stair_4s

simple_models.slope_1x1x1:
- fields:
  - mesh: "simple_models_slope_1x1x1.obj"
  - box:  {
      {-0.5, -0.5,  0.4, 0.5,  0.5, 0.5},
      {-0.5, -0.5,  0.3, 0.5,  0.4, 0.5},
      {-0.5, -0.5,  0.2, 0.5,  0.3, 0.5},
      {-0.5, -0.5,  0.1, 0.5,  0.2, 0.5},
      {-0.5, -0.5,  0.0, 0.5,  0.1, 0.5},
      {-0.5, -0.5, -0.1, 0.5,  0.0, 0.5},
      {-0.5, -0.5, -0.2, 0.5, -0.1, 0.5},
      {-0.5, -0.5, -0.3, 0.5, -0.2, 0.5},
      {-0.5, -0.5, -0.4, 0.5, -0.3, 0.5},
      {-0.5, -0.5, -0.5, 0.5, -0.4, 0.5},
    }
- alias: simple_models.slope

simple_models.slope_1x1x2:
- fields:
  - mesh: "simple_models_slope_1x1x2.obj"
  - box:  {
      {-0.5, -0.5,  0.3, 0.5,  0.5, 0.5},
      {-0.5, -0.5,  0.1, 0.5,  0.4, 0.5},
      {-0.5, -0.5, -0.1, 0.5,  0.3, 0.5},
      {-0.5, -0.5, -0.3, 0.5,  0.2, 0.5},
      {-0.5, -0.5, -0.5, 0.5,  0.1, 0.5},
      {-0.5, -0.5, -0.7, 0.5,  0.0, 0.5},
      {-0.5, -0.5, -0.9, 0.5, -0.1, 0.5},
      {-0.5, -0.5, -1.1, 0.5, -0.2, 0.5},
      {-0.5, -0.5, -1.3, 0.5, -0.3, 0.5},
      {-0.5, -0.5, -1.5, 0.5, -0.4, 0.5},
    }
- alias: simple_models.slope_long

Helper Methods

There are some helper methods to make opening & closing door-like nodes simpler. They take the parameters pos, new_node, & invert. If invert is set to true, doors will swing in the opposite direction:

simple_models:door_inward_open
- Helper method for inward opening door-like nodes.

simple_models:door_inward_close
- Helper method for inward closing door-like nodes.

simple_models.door_outward_open
- Helper method for outward opening door-like nodes.

simple_models.door_outward_close
- Helper method for outward closing door-like nodes.

Example usage:

core.register_node("simple_models:door_l_closed", {
    on_rightclick = function(pos, node, clicker, stack, pointed_thing)
        simple_models:door_inward_open(pos, "simple_models:door_l_open")
        return stack
    end,
})

core.register_node("simple_models:door_r_closed", {
    on_rightclick = function(pos, node, clicker, stack, pointed_thing)
        simple_models:door_inward_open(pos, "simple_models:door_r_open", true)
        return stack
    end,
})

Samples

To use sample nodes, enable the setting simple_models.enable_samples.

Sample nodes include:

• simple_models:node_tall
• simple_models:panel
• simple_models:panel_mid
• simple_models:panel_rear
• simple_models:door_l_in_closed
• simple_models:door_l_in_open
• simple_models:door_l_out_closed
• simple_models:door_l_out_open
• simple_models:stair_2s
• simple_models:stair_4s
• simple_models:slope
• simple_models:slope_long

If there are suggestions for others dimensions, I would like to hear them. I want to practice a bit more with very simple 3D modeling.
